Material Properties
Width (mm)
± 2 mm |
No. of Bundles
x No. of Wires |
Total No. of
Wires ± 10 |
Wire Diameter
mm ± 0.003 |
Normal Cross
Sectional Area
(mm2 ) ± 3 mm2 |
| 10* |
24x10 |
240 |
.19 |
6.8 |
| 12* |
24x14 |
336 |
.19 |
9.53 |
| 16 |
24x24 |
576 |
.19 |
16.3 |
| 20 |
24x30 |
720 |
.19 |
20.4 |
| 25 |
48x15 |
720 |
.19 |
20.4 |
| 25 |
48x20 |
960 |
.19 |
27.2 |
| 30 |
48x24 |
1152 |
.19 |
32.6 |
| 35 |
48x30 |
1440 |
.19 |
40.8 |
| 40 |
48x36 |
1728 |
.19 |
49.0 |
| 35 |
48x28
48x24 |
2496 |
.19 |
70.73 |
| 40 |
48x36
48x32 |
3360 |
.19 |
95.21 |
|
24x17 |
408 |
.19 |
11.6 |
